MODE

Car battery

Start-stop battery

Motorcycle batter

Recovery

Charging Mode

7 stage charging

steps:Desulphurization,Soft Start,Bulk

charging,Absorption,Battery Test,Recondition,Float charging

6 stage charging

steps:Soft Start,Bulk  charging、,Absorption,Battery Test

Recondition,Float charging

recovery mode continue working 15-16h

Features

(1) Output short circuit and anti reverse connection;

(2) Charging over-current warning;

(3) Charging memory function;

(4) Seven stage charging state can be displayed;

(5) Battery level detection:

(6) Winter/summer mode;

(7) Over-temperature and overcharge protection;

(8) Charging voltage self-test;

(9) Key anti false triggering;

(10) Micro control chip.

Input V

100V-240V

Output V

5V-31.5V

12V Charging voltage

14.6V-15.5±0.2V

14.6V±0.2V

24V Charging voltage

29.2V-30V±0.2V

29.2V±0.2V

12V output current

7A

24V output current

3±0.3A

Suitable battery range

12V/24V  2AH-200AH Lead acid battery / start stop battery（not suitable for lithium battery）
